Quick Details

  • Condition: New
  • Type: Agro-Forestry Monitoring System
  • Use: Forest Machine
  • Power Type: Gasoline
  • Production Capacity: 1000
  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: 4WMOTO
  • Model Number: Grapple Crane 350 With Hydraulic Tip Box
  • Dimension(L*W*H): 2010*1330*400 for box
  • Weight: 800 kg
  • Certification: CE Certificate
  • Warranty: 1 Year
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Color: Black, red, green

Packaging & Delivery

Packaging Details Crated
Delivery Time 60-70 Days
Crane 350 Specification
Model Name:Grapple Crane 350 -I without automatic rolldrive
 Grapple Crane 350-II 4x4 with automatic rolldrive
Engine:7HP/5kw, pull start
Max rotary speed:3000r/m
Pressure of oil pump: 16MPa
Pump supply oil flow:4ML/R
Working temperture:-40to 80
Length of crane arm:3.5M
Lifting capacity of Max.arm reach:200kg
Swing angle:+-90
Hydraulic Oil Tank:7.2L
Fuel Tank:4L
Weight of crane:90kg
Whole machine weight of Crane 350-I ;580kg
Whole machine weight of Crane 350-II:630kg
Max loading of trailer:1500kg
2006/42/EC certification

Hydraulic winch Specification
remote control:waterproof
Remote control area30M
Rated line pull:800KG
Speed:10-25m/min
Wire thickness:5mm
Wire length:18m



Hydraulic Tip Box for 350 Timber Trailer with Crane  Specification:

Model No:Hydraulic Tipping Box for Crane 350
Weight of box :170kg170kg
Demension of box(LWH):2010x1330x400 mm
Remark:Accessory for Grapple Crane 350
